Horizontal Scrap Metal Shear With Feeding Conveyor 1200mm Blade Length

Model Number : WS-4000

Place of Origin : made in china

MOQ : 1

Supply Ability : 10 set/ month

Packaging Details : Seaworthy Packing

Brand Name : DLK

Delivery Time : 30 days

Application : Scrap Metal

Press Box Size (L*W*H)mm : 2400*1400*1985

Electric : 380v/3HP 50HZ

Shear Time : 2.5 time / min

Driven Type : Hydraulic

Feeding Open(L*W*H)mm : 3075*2200*860

Quality : Grade A

Price : Negotiation

Contact Now

1200mm Trapeziform Blade Length Scrap Metal Shear , WS - 4000 Medium Machine

Corporate Mission
We will enter into everywhere in the world.
Make all customers be proud of our products.
Trying to be the leader of our business line.

Company Culture
To become the best employees, create high quality products, creat first-class business
Strengthen management, improve service, brand first, quality first
Faith based, innovation, common development

Applications

The WS-4000 AUTOMATIC HORIZONTAL SHEARING MACHINE which is widely used in recycling companies and ferrous & non-ferrous metal smelting industry , can help to shear metal scrap(steel parings, waste steel, waste copper & aluminum, waste stainless steel, scrap from discarded automobiles)

Important Parameters

model :WS-4000

max cutting force :4000KN

blade length;1400mm

production rate:4-7t/h

Technical Specifications						Remark
Shear cylinder	model		YG340/220-800			2 sets
	Nominal pressure		2000KN*2	Trip	800MM
press cylinder	model		YG250/160-700			1 set
	Nominal pressure		120KN	Trip	800MM
motor	model	Y250M-6		Power	17kw
	speed	980 R / MIN		Quantity	2 sets
oil pump	Model	HY250Y-RP		Pressure	31.5 mpa
	Oil flow	250 ml / r		Quantity	2 sets
